11 Supplement
VEGAPULS 64 • Two-wire 4 … 20 mA/HART
51141-EN-210219
VEGAPULS64,hygienicttingwithencapsulatedantennasystem1
CA
68,5 mm
(2.70")
16,5 mm
(0.65")
ø 40 mm
(1.57")
ø 51,6 mm
(2.03")
ø 43,8 mm
(1.73")
ø 64 mm
(2.52")
95,6 mm
(3.76")
32 mm
(1.25")
ø 40 mm
(1.57")
ø 89,8 mm
(3.53")
ø 79 mm
(3.12")
ø 106 mm
(4.17")
19 mm
(0.75")
69,9 mm
(2.75")
ø 45 mm
(1.77")
ø 68,5 mm
(2.70")
Rd 110x1/6
Rd 78x1/6
ø 40 mm
(1.57")
32 mm
(1.25")
97 mm
(3.82")
ø 75 mm
(2.95")
ø 99 mm
(3.91")
ø 40 mm
(1.57")
CE
RA RD
Fig. 68: VEGAPULS 64, hygienic tting with encapsulated antenna system
CA Clamp 2" PN 16 (DIN 32676, ISO 2852)
CE Clamp 3½" PN 16 (DIN 32676, ISO 2852)
RA Slotted nut DN 50 PN 16 (DIN 11851)
RD Slotted nut DN 100 PN 16 (DIN 11851)
