2.3 Installation of equipment
If your payment terminal and PINpad were delivered as a plug & play pack, you must install the
equipment yourself. Connect the equipment as depicted below.
If you need to temporarily disconnect the equipment (e.g. because you wish to relocate it), you can
reconnect it as depicted below.
Plug into wall socket
(230 Volt)
Hook up to
Ethernet modem
or router

VeriFone CCV Smart VX 820 Specifications

General

Brand	VeriFone
Model	CCV Smart VX 820
Category	Payment Terminal
Language	English
