TERMINAL SETUP
Connecting the Terminal Power Pack
28 OMNI 5XXX AND V
X
5XX/V
X
610 INSTALLATION GUIDE
Connecting the
Terminal Power
Pack
When you have finished connecting optional peripheral(s), you are ready to
connect the V
x
5xx/V
x
610 terminal to the provided power source.
To Connect the
Terminal Power Pack
1 Insert the round barrel connector (see Figure 20, Figure 21 and
Figure 22) into the power port, identified by the icon at right.
Figure 20 V
x
510 Power Pack Connection
Figure 21 V
x
570 Power Pack Connection
CAUTION
Using an incorrectly rated power supply may damage the terminal or cause it not
to work as specified. Before troubleshooting, ensure that the power supply being
used to power the terminal matches the requirements specified on the bottom of
the terminal. (See Chapter 3, Specifications, for detailed power supply
specifications.) Obtain the appropriately rated power supply before continuing
with troubleshooting.
NOTE
Plugging in the power pack to a power source automatically turns on the terminal.
