TERMINAL SETUP
Connecting Optional Device(s)
24 OMNI 5XXX AND V
X
5XX/V
X
610 INSTALLATION GUIDE
Connecting
Optional
Device(s)
The V
x
5xx/V
x
610 series of terminals supports some peripheral devices designed
for use with electronic point-of-sale terminals.
Different terminals support different devices, so for more information about
optional devices, please contact your VeriFone distributor.
V
x
510 and V
x
570
Optional Device
Connections
For the V
x
510 and V
x
570, use the two ports on the back panel to connect up to
two optional devices.
Connecting the PINpad or Smart Card Reader to the V
x
510
or V
x
570
Use the following procedure to connect a PINpad or smart card reader.
1 Insert the RJ45-type connector on the end of the PINpad or smart card reader
into the port on the back of the peripheral device.
To install a PINpad 101, PINpad 201, or PINpad 1000, position and insert the
grommet to secure the cable connection.
If a cable is not already connected to the smart card reader or PINpad, insert
the small modular plug on one end of the interface cable into the optional
device’s modular jack.
CAUTION
Before connecting any peripheral device, remove the power cord and/or battery
(see Installing the V
x
610 Smart Battery) from the terminal and ensure that the
green indicator LED is not lit. Reconnect the power cord and/or battery only after
you are finished connecting the peripheral device(s). For complete information
about peripheral installation and use, refer to the user documentation supplied
with those devices.
NOTE
RS-232-type devices do not work on the PINpad port. PINpad-type devices do not
work on the RS-232 port. If an optional peripheral device does not function
correctly, check the port connection.
