VeriFone VX 520 Reference Guide

TERMINAL SETUP
Installing the Smart Battery (VX 520 GPRS Only)
VX 520 R
EFERENCE GUIDE 21
Installing the
Smart Battery
(VX 520 GPRS
Only)
The smart battery fits in a slot on the back of the VX 520 GPRS terminal. The
locking tab clicks when the battery is in place. The slot is keyed, so that there is
only one way to insert the battery.
Figure 6 Installing the Smart Battery
Removal
To remove the VX 520 GPRS smart battery, press the locking tab and pull the
smart battery from its slot.
Figure 7 Removing the Smart Battery

VeriFone VX 520 Specifications

General

Processor	400 MHz ARM11
Card Readers	Magnetic stripe, EMV chip
Operating Temperature	0°C to 50°C (32°F to 122°F)
Display	128x64 pixel backlit LCD
Connectivity	Dial-up, Ethernet
Contactless	Optional
Printer	18 lines per second
Security	PCI PTS 3.0 approved
Weight	500g
Dimensions	203 mm x 87 mm x 77 mm (8.0 in x 3.4 in x 3.0 in)
