VeriFone VX690 User Manual

Live epos integrated User Guide 7
2.1 Using the Touch Screen
The Live epos integrated terminal has a colour touch screen. To navigate using the touch
screen, follow the prompts and press the opon on the screen to make a selecon.
2.2 Using the Keypad
2.0 Setup and conguraon
Key Title Symbol Key Purpose
Enter
Clear/Back
Cancel
This buon on the terminal keypad is used to accept data entry or
proceed with a funcon and is the same as using the SELECT or OK
buons displayed on the touch screen. This buon is also used to
power on the terminal when held down for 10 seconds.
This buon on the terminal keypad is used for clearing entered data
or moving back to the previous screen and is the same as using the
CLEAR or BACK buons displayed on the touch screen.
This buon on the terminal keypad is used to cancel the current
funcon and return to the home screen and is the same as using the
CANCEL or NO buons displayed on the touch screen. This buon is
also used to power off the terminal when held down for 10 seconds.

VeriFone VX690 Specifications

General

Display	3.5-inch color LCD
Card Reader	MSR
Connectivity	Wi-Fi, Bluetooth
Battery	Rechargeable Li-ion
Dimensions	172mm L x 82mm W x 63mm H
Security	PCI PTS approved
Operating System	Verix
