PCB with Components (W/ VR-UNIT) CP6946002 VERSION D
CP6946004 VERSION A
CP6946006 VERSION CS
CP6946012 VERSION F
Printed Circuit Board FR006560C 1-4
Printed Circuit Board FR006560D 5-24
Printed Circuit Board FR006560E 25-
C 1001 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 1- B c1
C 1002 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B c2
C 1003 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B b2
C 1004 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C7
C 1005 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DZ01D K22178210 1-6 B c2
C 1005 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 VERSION CS 7- B c2
C 1005 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 VERSION A 7- B c2
C 1005 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DZ01D K22178210 VERSION D 7- B c2
C 1005 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DZ01D K22178209 VERSION F 8- B c2
C 1006 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1007 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a4
C 1008 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C3
C 1009 CHIP CAP. 2pF 50V CK GRM1554C1H2R0CZ01D K22178204 1- B c2
C 1009 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 6 B c2
C 1009 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 VERSION CS 7- B c2
C 1009 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BZ01D K22178290 VERSION A 7- B c2
C 1009 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 VERSION D 7- B c2
C 1009 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 VERSION F 8- B c2
C 1010 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C4
C 1011 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 1-6 B c2
C 1011 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 VERSION CS 7- B c2
C 1011 CHIP CAP. 8pF 50V CH GRM1552C1H8R0DZ01D K22178210 VERSION A 7- B c2
C 1011 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DZ01D K22178209 VERSION A 10- B c2
C 1011 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 VERSION D 7- B c2
C 1011 CHIP CAP. 5pF 50V CH GRM1552C1H5R0CZ01D K22178207 VERSION F 8- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM1554C1H2R0CZ01D K22178204 1- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 6 B c2
C 1013 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 VERSION CS 7- B c2
C 1013 CHIP CAP. 3pF 50V CJ GRM1553C1H3R0BZ01D K22178290 VERSION A 7- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 VERSION D 7- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 VERSION F 8- B c2
C 1015 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 1- B b2
C 1016 CHIP CAP. 0.0027uF 50V B GRM155B11H272KA01D K22178814 1- B a4
C 1017 CHIP TA.CAP. 4.7uF 6.3V TMCMA0J475MTR K78080026 1- B a4
C 1018 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 1- B b2
C 1019 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DZ01D K22178209 1-6 B c2
C 1019 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DZ01D K22178209 VERSION CS 7- B c2
C 1019 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 VERSION A 7- B c2
C 1019 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DZ01D K22178209 VERSION D 7- B c2
C 1019 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 VERSION F 8- B c2
C 1020 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 1-7 B c2
C 1020 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 VERSION CS 8- B c2
C 1020 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 VERSION A 8- B c2
C 1020 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 VERSION D 8- B c2
C 1020 CHIP CAP. 0.5pF 50V CK GRM1554C1HR50BZ01D K22178285 VERSION F 8- B c2
C 1021 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B a7
C 1023 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B a7
C 1024 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2
C 1025 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 1-7 B c2
C 1025 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 VERSION CS 8- B c2
C 1025 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 VERSION A 8- B c2
C 1025 CHIP CAP. 1pF 50V CK GRM1554C1H1R0CZ01D K22178202 VERSION D 8- B c2
Parts List
Main Unit
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR
To Next Page
