Vertex Standard VX-600 - Parts List; C 1ｘｘｘ; D 1 xxx; J 1 xxx

61
F2D-8 2-Tone Decode Unit
Parts List
*** F2D-8 ***
Printed Circuit Board FR002530C 1-
C 1001 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- A
C 1002 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1003 CHIP CAP. 0.01uF 25V B GRM39B103K25PT K22144803 1- A
C 1007 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1007 CHIP CAP. 0.0015uF 50V B GRM39B152M50PT K22174811 6- A
C 1007 CHIP CAP. 0.01uF 50V B GRM39B103M50PT K22174823 18- A
C 1008 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1009 CHIP CAP. 0.0018uF 50V B GRM39B182M50PT K22174812 1- A
C 1010 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1011 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1012 CHIP CAP. 47pF 50V CH GRM39CH470J50PT K22174227 1- A
C 1013 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1014 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
D 1001 DIODE DA221 TL G2070178 1- A
D 1002 DIODE 1SS355 TE-17 G2070470 1- A
J 1001 CONNECTOR AXK5S40035P P1091012 1- A
Q 1001 IC HD64F3334YTF16 R0226 G1092873 1- A
Q 1003 IC TC7S04FU TE85R G1091530 1- A
Q 1004 IC TA75S01F TE85R G1091593 1- A
Q 1005 TRANSISTOR DTC124TU T106 G3070065 1- A
R 1001 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A
R 1002 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A
R 1003 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1004 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1005 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1006 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1007 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1008 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- A
R 1009 CHIP RES. 4.7k 1/16W 5% RMC1/16 472JATP J24185472 1- A
R 1009 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 6- A
R 1010 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A
R 1015 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A
R 1016 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A
R 1016 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 6- A
R 1017 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A
BLIND SHEET RA0109300 1-
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR
