FVP-25 Encryption / DTMF Pager Unit
Parts List
*** FVP-25 ***
Printed Circuit Board FR005010F
C 1001 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1002 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A
C 1003 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- A
C 1004 CHIP CAP. 10pF 50V CH GRM39CH100D50PT K22174211 1- A
C 1005 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1007 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1008 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1009 CHIP CAP. 68pF 50V CH GRM39CH680J50PT K22174231 1- A
C 1010 CHIP CAP. 390pF 50V CH GRM39CH391J50PT K22174255 1- A
C 1011 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1012 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- A
C 1013 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1- A
C 1014 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
D 1001 DIODE 1SS355 TE-17 G2070470 1- A
D 1002 DIODE 1SS355 TE-17 G2070470 1- A
J 1001 CONNECTOR AXK5S40035P P1091012 1- A
Q 1001 IC M64026FP-650C G1092754 1- A
Q 1002 IC LC73881M-TLM G1092755 1- A
Q 1003 TRANSISTOR DTC144EU T106 G3070041 1- A
R 1001 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1002 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- A
R 1003 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A
R 1004 CHIP RES. 680k 1/16W 5% RMC1/16 684JATP J24185684 1- A
R 1006 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A
R 1007 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- A
R 1008 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1008 CARBON FILM RES. 22k 1/8W 5% RD18TJ223 22K J01215223 14- A
R 1008 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 17- A
X 1001 XTAL SX-1315 3.6263MHz 3.6263MHZ H0103183 1- A
X 1002 XTAL SX-1315 4.194304MHz 4.194304MHZ H0103184 1- A
BLIND SHEET RA0109300 1-
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
