Vertex Standard VX-600 - Parts List; C 1 xxx; D 1 xxx; J 1 xxx

67
F5D-14 5-Tone Unit
Parts List
*** F5D-14 ***
Printed Circuit Board FR0065100 1-
C 1001 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A
C 1002 CHIP CAP. 0.0018uF 50V B GRM36B182K50PT K22178812 1- A
C 1003 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A
C 1005 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A
C 1006 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A
C 1007 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A
C 1008 CHIP TA.CAP. 10uF 6.3V EEJK0JS106R K78080079 1- A
C 1009 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A
C 1010 CHIP CAP. 0.0027uF 50V B GRM36B272K50PT K22178814 1- A
C 1011 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A
C 1012 CHIP CAP. 18pF 50V CH GRM36CH180J50PT K22178218 1- A
C 1013 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A
C 1014 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A
C 1015 CHIP CAP. 18pF 50V CH GRM36CH180J50PT K22178218 1- A
C 1016 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- A
C 1017 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A
C 1018 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A
C 1019 CHIP TA.CAP. 1uF 6.3V TMCP0J105MTR K78080071 1- A
D 1001 DIODE MA2S111-(TX) G2070614 1- A
J 1001 CONNECTOR AXK5S40035P P1091012 1- A
L 1001 M.RFC 22uH ELJ-FC220K L1690201 1- A
Q 1001 IC TK71650SCL G1093136 1- A
Q 1002 TRANSISTOR DTC114TE TL G3070225 1- A
Q 1003 IC PIC17LC44-08/PQ S8100917 1- A
Q 1004 TRANSISTOR 2SC4617 TL R G3346178R 1- A
Q 1005 IC MD09 G1093276 1- A
Q 1006 IC BR93LC66FV-E2 G1092853 1- A
R 1001 CHIP RES. 18k 1/16W 5% RMC1/16S 183JTH J24189040 1- A
R 1002 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A
R 1003 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A
R 1004 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A
R 1005 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A
R 1006 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- A
R 1007 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A
R 1008 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A
R 1009 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A
R 1010 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A
R 1011 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 1012 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A
R 1013 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A
R 1014 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- A
R 1015 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 1016 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A
R 1017 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A
R 1018 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A
R 1019 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A
R 1020 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A
R 1021 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A
R 1022 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A
R 1023 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A
X 1001 XTAL 94SMX 8MHz 8.000MHZ H0103248 1- A
BLIND SHEET RA0109300 1-
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR
