Vertex Standard VX-600 - Parts List; C 1 xxx; D 1 xxx; J 1 xxx

63
VTP-50 VX-Trunk Unit
Parts List
*** VTP-50 ***
Printed Circuit Board FR002540C 1-
C 1002 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1003 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A
C 1004 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1005 CHIP CAP. 0.01uF 25V B GRM39B103M25PT K22144802 1- A
C 1006 CHIP CAP. 10pF 50V CH GRM39CH100C50PT K22174248 1- A
C 1007 CHIP CAP. 10pF 50V CH GRM39CH100C50PT K22174248 1- A
C 1008 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1009 CHIP TA.CAP. 4.7uF 6.3V TEMSVA0J475M-8R K78080017 1- A
C 1010 CHIP CAP. 0.0018uF 50V B GRM39B182M50PT K22174812 1- A
C 1011 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1012 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
C 1013 CHIP CAP. 0.001uF 50V B GRM39B102K50PT K22174821 1- A
C 1014 CHIP CAP. 0.1uF 16V B GRM39B104K16PT K22124805 1- A
D 1001 DIODE 1SS355 TE-17 G2070470 1- A
J 1001 CONNECTOR AXK5S40035P P1091012 1- A
Q 1001 IC NJM2904V-TE1 G1091677 1- A
Q 1002 IC MC68HSC705C8A502 G1092917 1- A
Q 1003 IC TA75S01F TE85R G1091593 1- A
Q 1004 IC BR93LC56FV-E2 G1092787 1- A
R 1001 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A
R 1002 CHIP RES. 680k 1/16W 5% RMC1/16 684JATP J24185684 1- A
R 1003 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A
R 1004 CHIP RES. 470k 1/16W 5% RMC1/16 474JATP J24185474 1- A
R 1005 CHIP RES. 120k 1/16W 5% RMC1/16 124JATP J24185124 1- A
R 1006 CHIP RES. 680k 1/16W 5% RMC1/16 684JATP J24185684 1- A
R 1007 CHIP RES. 330k 1/16W 5% RMC1/16 334JATP J24185334 1- A
R 1008 CHIP RES. 150k 1/16W 5% RMC1/16 154JATP J24185154 1- A
R 1009 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- A
R 1010 CHIP RES. 39k 1/16W 5% RMC1/16 393JATP J24185393 1- A
R 1011 CHIP RES. 20k 1/16W 1% RMC1/16 203FTP J24183203 1- A
R 1012 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1013 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1014 CHIP RES. 1M 1/16W 5% RMC1/16 105JATP J24185105 1- A
R 1015 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1016 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1017 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1018 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1019 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A
R 1020 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A
R 1021 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A
R 1022 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- A
R 1023 CHIP RES. 560k 1/16W 5% RMC1/16 564JATP J24185564 1- A
R 1024 CHIP RES. 18k 1/16W 5% RMC1/16 183JATP J24185183 1- A
R 1025 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A
R 1026 CHIP RES. 470k 1/16W 5% RMC1/16 474JATP J24185474 1- A
R 1027 CHIP RES. 68k 1/16W 5% RMC1/16 683JATP J24185683 1- A
R 1028 CHIP RES. 33k 1/16W 5% RMC1/16 333JATP J24185333 1- A
X 1001 XTALSX-1315 3.579545MHz 3.579545MHZ H0103185 1- A
BLIND SHEET RA0109300 1-
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR
