Vertical Express LD-16 - Page 107

LD-16 Door Operator - Modernization Harness Assembly Diagrams
October 2021 - 88420 v.1.0
A-11
Harness Assembly Diagrams - COP Adapter, 462AEM_
(continued)
OPERR
12"
36"
203
PIN 1
PIN 1
PIN 1
SIR CON1
118X
PIN 1
Type: Door Operator
Use: TAC22, ICON, TAC20-03, TAC20, TAC50-03
Rear: 462AEM009
300
INS2
PIN 1
PIN 1
12"
Type: Inspection
Use: TAC32T
Front: 462AEM010
