Harness Assembly Diagrams LD-16 Door Operator - Modernization
A-12 © Vertical Express
Harness Assembly Diagrams - COP Adapter, 462AEM_
(continued)
INS2
300
PIN 1
INNO
INNC
INCOM
INUP
INDN
PIN 1
12"
Type: Inspection
Use: TAC32H
Front: 462AEM011
PIN 1
12"
FASTON - MALE
ALRM
PIN 1
BLK ALRM –
RED ALRM+
210A
Type: Alarm
Use: TAC32T, TAC32H
Front: 462AEM012
35"
12"
PIN 1
PIN 1
PIN 1
PIN 1
210
ALRM
SIF CON11
SIF
CON3
Type: Alarm, 485
Use: TAC22, ICON, TAC20-03, TAC20, TAC50-03
Front: 462AEM0013
