Vertiv CoolPhase CDU - Field Electrical Connections

REV : B
REV DATE : 03/24
10032075
Page :1 /2
LIEBERT® MCV430 (2) + LIEBERT® ECONOPHASE (2)
+ BASE ASSEMBLY
Form No.: DPN001040_REV4
PRIMARY CONNECTION LOCATIONS
LIEBERT
®
HEAT REJECTION SKID
Notes:
1. Field to provide hole for conduit for high voltage disconnect box and low voltage distribution panel.
Front of Unit
A
DETAIL A
Field Electrical Connections
SYSTEM 1 CIRCUIT 1
SYSTEM 1 CIRCUIT 2
25 3/4"
655mm
Bottom of Box
54 3/4"
1390mm
Center of Box
74 3/4"
1898mm
Center of Box
87 1/2"
2223mm
Center of Box
92"
2337mm
Center of Box
High Voltage
Customer
Connection
System 1
High Voltage
Customer
Connection
System 2
Low Voltage Customes Connection
System 2
Low Voltage Customes Connection
System 1
64 1/4"
1632mm
27 3/8"
696mm
Bottom of Box
34"
864mm
Bottom of Box
123 1/2"
3138mm
101 1/4"
2572mm
