Dual Disconnect for Compressors (Rev Starter, Cond Sub-feed) with Separate Disconnect for Pumps and Controls
Unit Voltage Rating
Dual Disconnects Dual Disconnects Pumps/Controls Disconnect
XDM300+MCV430+PRE XDM300+MCV440+PRE XDM300 Pumps
460V/60Hz
10HP
FLA 124.4 130 22.6
WSA 131.1 136.7 25.4
OPD 150 150 35
460V/60Hz
15HP
FLA 124.4 130 34
WSA 131.1 136.7 38.3
OPD 150 150 50
Single Disconnect
Unit Voltage Rating XDM200
460V/60Hz
7.5HP
FLA 91.8
WSA 97.0
OPD 110
460V/60Hz
5.0HP
FLA 88.7
WSA 93.9
OPD 110
Dual Disconnect (Rev Starter, Cap Buffer, and Cond Sub-feed)
Unit Voltage Rating XDM200 + MCV330 + PRE XDM200 + MCV440 + PRE
460V/60Hz
7.5HP
FLA 108.6 114.2
WSA 113.8 119.4
OPD 125 125
460V/60Hz
5.0HP
FLA 105.5 111.1
WSA 110.7 116.3
OPD 125 125
Single Disconnect
Unit Voltage Rating XDM300
460V/60Hz
10 HP
FLA 130.2
WSA 136.9
OPD 150
460V/60Hz
15 HP
FLA 141.6
WSA 148.3
OPD 175
Dual Disconnect (Rev Starter, Cap Buffer, and Cond Sub-feed)
Unit Voltage Rating XDM300 + MCV430 + PRE XDM300 + MCV440 + PRE
460V/60Hz
10HP
FLA 147 152.6
WSA 153.7 159.3
OPD 175 175
460V/60Hz
15HP
FLA 158.4 164
WSA 165.1 170.7
OPD 175 175
COOLPHASE CDU & LIEBERT® XDM
ELECTRICAL DATA
FORM NO. DPN004906 REV C
DPN005241
REV: E
REV DATE: 08/2024
REVISIONS
REV. DESCRIPTION
DATE DRAWN BY
DATE APPROVED BY
A
INITIAL RELEASE 02/23/2024 S. BARMAN
02/23/2024 J. MURPHY
B
UPDATED TEMPLATE. CHGD
PRODUCT NAME TO COOLPHASE CDU.
08/27/2024 M. ADAMS
08/27/2024 J. MURPHY
FLA = Full Load Amps; WSA = Wire Size Amps; OPD = Maximum Overcurrent Protection Device
Note: The XDM400 consists of two separate XDM200 electrical feeds.
FLA = Full Load Amps; WSA = Wire Size Amps; OPD = Maximum Overcurrent Protection Device
Note: The XDM400 consists of two separate XDM200 electrical feeds.
FLA = Full Load Amps; WSA = Wire Size Amps; OPD = Maximum Overcurrent Protection Device
FLA = Full Load Amps; WSA = Wire Size Amps; OPD = Maximum Overcurrent Protection Device
Note: These values are for units using 410a refrigerant, with no A2L mitigation.
