5 Refrigerant Piping Requirements
The main fluid connections are flange fittings with a factory installed plate. These connections may be at the top of the unit.
• Field installed refrigerant piping must be installed in accordance with local codes and must be properly
assembled, supported, isolated, and insulated. Avoid piping runs through noise sensitive areas, such as office
walls and conference rooms.
• Refer to specific text and detailed diagrams in this manual for other unit specific piping requirements.
• All piping will be elevated above the unit and must be arranged so that it offers the least resistance. Careful
planning of the piping layout above the raised floor is required. When installing piping above the unit, we
recommend installing the pipes in a horizontal plane rather than stacked one above the other.
• Whenever possible, the pipes should be run parallel.
• Install shutoff ball valves on the inlet and outlet pipes to ease maintenance.
• Install optional thermostats and pressure gauges on the inlet and outlet pipes.
The pipe connection locations, piping general arrangement and schematics are described in the submittal documents
included in Submittal Drawings on page107
The following tables list the relevant documents by number and title.
Document Number Title
20000059, p1 CoolPhase CDU Piping Schematic Liebert® XDM with Vertiv™ Liebert® MCV
20000059, p2 CoolPhase CDU Piping Schematic Liebert® XDM Secondary Coolant Loop
10025700 Glycol and Water Requirements
Table 5.1 Piping General Arrangement Drawings
Document Number Title
20000057 CoolPhase CDUPrimary Connections Top (Fluid and Refrigerant) 300kW
Refrigeration Piping Layout and Condenser Positioning Drawings
20000101, p1 CoolPhase CDU Air Cooled Piping Schematic Liebert® MCV Mounted above Liebert® XDM
20000101, p2 CoolPhase CDU Piping Schematic Liebert® MCV and Liebert® XDM at Similar Level
Table 5.2 Piping Connection Drawings
5 Refrigerant Piping Requirements Proprietary and Confidential ©2024 Vertiv Group Corp. 45
Vertiv™ CoolPhase CDU Installer/User Guide
