Vertiv CoolPhase CDU - Additional Oil Requirements for Scroll and Digital Scroll Compressors

Heat Rejection Skid System No Circuit No. Charge per Circuit lb (kg)
Liebert® MCV430 and MCV440 Single skid with (1) PRE unit 1
1
62 (28.1)
2
Liebert® MCV430 and MCV440 Dual skid with (2) PRE units
1
1
62 (28.1)
2
2
1
2
The heat rejection skid contains:
• Liebert® MCV condensers
• Liebert® EconoPhase (PRE) units, and all internal piping.
Liebert® receivers are used with Liebert® MCV440 heat rejections when the outdoor ambient is above 105°F.
Table 5.6 Approximate R-410A Refrigerant Required per Circuit for Vertiv™ Liebert® MCV Heat Rejection Skid
Line Size, OD (in) Liquid Line (in/mm) Hot Gas Line (in/mm)
1-3/8
51.5
(23.0)
5.9
(2.6)
1-5/8 —
8.4
(3.7)
Source: DPN003099, Rev. 1
Table 5.7 Interconnecting Piping Refrigerant Charge for R-410A, lb. per 100 ft. (kg per 30 m)
System Type Model Charge per Circuit, lb. (kg)
Liebert® EconoPhase Pumping Unit PR250 9.2 (4.2)
Table 5.8 Liebert® Pump Module Refrigerant Charge for R-410A per Circuit
5.4 Additional Oil Requirements for Scroll and Digital Scroll
Compressors
NOTICE
Risk of improper compressor lubrication. Can cause compressor and refrigerant system damage.
Failure to use oil types, viscosities, and quantities recommended by the compressor manufacturer may reduce
compressor life and void the compressor warranty. See Table 12.2 on page96 for the recommended oil for the
system.
• Do not mix polyolester (POE) and mineral based oils.
• Do not mix oils of different viscosities.
Consult your Vertiv sales representative, visit https://www.Vertiv.com/en-us/support/, or contact the compressor
manufacturer if questions arise.
5 Refrigerant Piping Requirements Proprietary and Confidential ©2024 Vertiv Group Corp. 51
Vertiv™ CoolPhase CDU Installer/User Guide
