Figure 2.7 Vertiv™ CoolPhase CDU with DCD in Hot/Cold Aisle Application
Item Description
1 Aisle pitch, 7 tiles, 14 ft. (4.3 m)
2 Cold aisle
3 Hot aisle
4 Cold aisle, 4 ft. (1.2 m)
5 Rack, 42 in. (1,067 mm)
6 Hot aisle, 3 ft. (0.91 m)
18 Proprietary and Confidential ©2024 Vertiv Group Corp. 2 Nomenclature and Components
Vertiv™ CoolPhase CDU Installer/User Guide
