5. Use a #2 Phillips screwdriver to install the module-securing bracket as shown in Lock lever and
module-securing bracket on page 30.
6. Replace the plastic bezels.
Figure 3.10 Lock lever and module-securing bracket
ITEM DESCRIPTION
1 Install module-securing bracket.
2 Pull out and down to secure lock lever.
Vertiv | Liebert® APS™ Installer/User Guide | 30
