MAXIMUM
SYSTEM
RATED
LOAD
INPUT VOLTAGE - 200VAC INPUT VOLTAGE - 208VAC INPUT VOLTAGE - 240VAC
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
5kVA 27A 50A 26A 50A 23A 50A
10kVA 53A 63A 51A 63A 45A 63A
15kVA 80A 100A 77A 100A 67A 100A
20kVA 106A 125A 102A 125A 90A 125A
The power input and output terminals accept a maximum cable cross-sectional area of 70mm
2
(2/0AWG); the minimum cable cross-sectional area is
16mm
2
(6AWG). The rated torque is 12.43Nm (110in-lb).
90°C copper wire recommended.
Table 3.5 Input cable selection for transformer-based frames (60 Hz)
MAXIMUM
SYSTEM
RATED
LOAD
INPUT VOLTAGE - 220VAC INPUT VOLTAGE - 230VAC INPUT VOLTAGE - 240VAC
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
5kVA 25A 50A 24A 50A 23A 50A
10kVA 49A 63A 47A 63A 45A 63A
15kVA 73A 100A 70A 100A 67A 100A
20kVA 97A 125A 93A 125A 90A 125A
The power input and output terminals accept a maximum cable cross-sectional area of is 70mm
2
(2/0AWG); the minimum cable cross-sectional area is
16mm
2
(6AWG). The rated torque is 12.43Nm (110in-lb).
90°C copper wire recommended.
Table 3.6 Input cable selection for transformer-based frames (50 Hz)
Configuring the Bypass Voltage
The UPS bypass voltage is factory-set to 208V (the jumper copper bar is installed). If you have a utility
supply of 200V/220V/230V/240V, you must change the bypass-voltage jumper to ensure correct
output voltages when in bypass mode. The bypass voltage jumper settings are shown in Figure 3.17 on
the next page and Figure 3.18 on the next page. Refer to Table 3.8 on page41 for the proper setting
according to the AC mains voltage configuration.
Vertiv | Liebert® APS™ Installer/User Guide | 37
