MAXIMUM
SYSTEM
RATED
LOAD
INPUT VOLTAGE – 200/100VAC INPUT VOLTAGE – 208/120VAC INPUT VOLTAGE – 240/120VAC
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
20kVA 91A 125A 83A 125A 83A 125A
The power input and output terminals accept a maximum cable cross-sectional area of 35mm
2
(2AWG); the minimum cable cross-sectional area is
16mm
2
(6AWG); and the rated torque is 4.52Nm (40in-lb).
90°C copper wire is recommended.
Table 3.10 Input cable selection for Transformer-free Dual Inverter frames(50/60 Hz) (continued)
MAXIMUM
SYSTEM
RATED
LOAD
INPUT VOLTAGE – 220/110VAC INPUT VOLTAGE – 230/115VAC INPUT VOLTAGE – 220/127VAC
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
MAXIMUM
CURRENT
IN UPS
MODE
RECOMMENDED
INPUT PROTECTION
CIRCUIT BREAKER
5kVA 21A 50A 20A 50A 20A 50A
10kVA 41A 63A 39A 63A 39A 63A
15kVA 62A 100A 59A 100A 59A 100A
20kVA 82A 125A 78A 125A 78A 125A
The power input and output terminals accept a maximum cable cross-sectional area of 35mm
2
(2AWG); the minimum cable cross-sectional area is
16mm
2
(6AWG); and the rated torque is 4.52Nm (40in-lb).
90°C copper wire is recommended.
Table 3.11 Input cable selection for Transformer-free Dual Inverter frames (50/60 Hz)
