PARAMETERS AS7EBCNCC1BX000
Transportation ISTA-1E
Dimensions, WxDxH 17x28x38 in. (440x712x970mm)
Unit Weight 147.7 lb.(67kg)
Shipping Weight 209.4 lb. (95kg)
Environmental
Operating Temperature 32 to 104°F (0 to 40°C)
Storage Temperature
Without battery: -4 to 140°F (-20 to 60°C)
With battery: 5 to 104°F (-15 to 40°C)
Relative Humidity 0 - 95%, non-condensing
Altitude 10,000 ft. (3000m)
Battery Module *
Lead-Acid Batteries (Per String) 12
Backup Time (Full Load), Minutes
See
,Estimated Battery Run Times: Model-number Digits 1-3 = AS1 or ASA on page 85 through
Estimated Battery Run Times: Model-number Digits 1-3 = AS6 or ASF on page 105
*Up to four external battery cabinets can be connected to each UPS frame and each external battery cabinet can be configured with up to seven strings
of batteries.
Table 8.3 Liebert APS external battery cabinet specifications (continued)
Vertiv | Liebert® APS™ Installer/User Guide | 84
