Nominal System Size Tons
Maximum Equivalent Pipe
Length, ft. (m)
Maximum PFH Level Above
Evaporator, ft. (m)
Maximum PFH Level Below
Evaporator, ft. (m)
5 150 (45) 50 (15) 15 (4.6)
Maximum recommended total equivalent pipe length is 150 ft (46m). Suction and liquid lines may require additional specialty items when vertical lines
exceed 20 ft. (6m) and/or condensing unit installation is more than 15 ft. (4.6m) below the evaporator. Contact Vertiv™ Application Engineering for
assistance.
Table 7.8 Pipe length and condenser elevation relative to evaporator
Refrigerant Charge Requirements—Total refrigerant charge will be required only if units are
evacuated during installation or maintenance. For safe and effective operation, refer to Piping
Connections and Coolant Requirements on page30.
Total refrigerant = Units and Lines*
Model #
R-407C, oz (kg)
60Hz 50Hz
MM*60E MM*59E 4 (0.11)
MM*60K MM*59K 4 (0.11)
MC*65A MC*64A 432 (12.3)
MC*69W MC*68W 94 (2.7)
PFH067A-_L7 PFH066A-_L7 426 (12.1)
PFH067A-_H7 PFH066A-_H7 827 (23.4)
PFHZ67A-_L7 PFHZ66A-_L7 827 (23.4)
All evaporator units and condensing units are fully factory-charged with refrigerant. If field-supplied refrigerant piping is installed, refrigerant must be
added; refer to Table 7.10 below to determine the additional charge.
Table 7.9 Refrigerant charge
Line Size, O.D., in.
R-407C, lb/100 ft. (kg/30m)
Liquid Line
Suction Line
3/8 3.7 (1.7)
—
1/2 6.9 (3.1)
—
5/8 11.0 (5.0 0.4 (0.2)
3/4 15.7 (7.1) 0.6 (0.3)
7/8 23.0 (10.4) 1.0 (0.4)
1-1/8
—
1.7 (0.7)
1-3/8
—
2.7 (1.1)
Table 7.10 Line charges - refrigerant
per 100 ft. (30m) of Type L copper
tube
Vertiv | Liebert Mini-Mate2—5 ton User Manual| 33
