Vertiv Liebert PEX4 Series User Manual

Vertiv | Liebert PEX4 | User Manual 46
Installation
No. Description No. Description
1 Pipeline 5 Remove transportation xing plate
2 Electronic humidication 6 Connect the electrode humidier with drain
pipe
3 Removable xing screw 7 Flip the electrode humidier as shown
4 Remove transportation xing screw 8 Connect the inlet of electrode humidier to
the hose pipe line.
Figure 2-30 Mounting of Electrode Humidifier
