Vertiv | Liebert PEX4 | User Manual 54
Installation
No. Description No. Description
1 Waterproof joint of external power cable 4 Waterproof joint of pressure sensor cable
2 Waterproof joint of compressor signal 5 Waterproof joint of fan power wire
3 Waterproof joint of spray module cable 6 Waterproof joint of fan over temperature
switch
Figure 2-33 External Power Supply Wiring Diagram Liebert LVC System
