Clutch cover retainer screws 10.8 to 12.8
End gear
Removing the hub cover
- Use a container large enough to recover the final
reduction oil. Unscrew the indicated screw and re-
cover the aluminium seal.
- Unscrew the oil filler screw in order to facilitate
bleeding.
Recommended products
AGIP GEAR SAE 80W-90 Lubricant for gear-
boxes and transmissions.
API GL-4
Characteristic
Hub oil
200 cm³
- Remove the brake shoe.
- Unscrew the eight hub cap fixing screws.
- Remove the final reduction cap complete with the
wheel axle, being careful not to drop the inter-
mediate gear.
Engine Vespa LX - S 125 3V ie 150 3V ie (2012)
ENG - 128

Vespa LX 2012 Specifications

General

Engine Type	Single-cylinder, 4-stroke
Displacement	124 cc
Cooling System	Air-cooled
Fuel System	Carburetor
Transmission	Automatic CVT
Fuel Tank Capacity	8.6 liters
Seat Height	785 mm
Curb Weight	114 kg
Length	1, 770 mm
Width	705 mm
Height	1, 140 mm
Max Power	10.3 hp @ 7, 750 rpm
Front Suspension	Single arm with coil spring and hydraulic shock absorber
Front Brake	200 mm
Rear Suspension	Coil spring and hydraulic shock absorber
Rear Brake	110 mm drum
