030624.13 25
vetus® Electronic engine remote control
6.1.1 CANBus data transmission cable
Length Code Length Code
L=3 m DTCAN3M L=10 m DTCAN10M
L=5 m DTCAN5M L=15 m DTCAN15M
L=7,5 m DTCAN7,5M
6.1.2 CANBus extension cable
Length Code
L=30 m DTCAN30M
L
Code B
Front view
Wire colour Function
White Signal
Yellow GND
L
L
6.1 CANBus cable
6.2 Cable for electronic engine
6.2.1 Cable for 1 electronic engine with 1 channel: voltage, PWM, 4-20 mA
Length Code
L=3 m EC3E3U
Important: this cable is without connector on engine side
