Vetus EC4 - Cable Actuator - Mercruiser Trim Pump

28 030624.13
vetus® Electronic engine remote control
6.5 Cable actuator – Mercruiser® trim pump
The cable for the trim pump of Mercruiser sterndrive has a length of 3 meters; in the cabling are included the fast-on
connections to the micro-switch for the end of stroke of the tilt.
Blue
Yellow
C
B
Blue
Mercruiser® trim pump sideActuator side
White
Fast-on receptable
Fast-on receptable
3 m (118
1
/
8
”)
0.6 m (23
5
/
8
”)0.15 m (5
7
/
8
”)
Length Code
L=3 m EC3T3MM
Trailer
Blue
Trim-
Green
Trailer
Blue
Trim-
Yellow
Mercruiser pump
Connector
Supply (non used)
Red (not used)
Connector
Actuator
Trim+
White
Mercruiser pump electric circuit
VETUS cable code:
Faston F
Blue
Violet
Faston F
Faston M
Faston M
NC Trailer switch
