vetus® Electronic engine remote control
10 Installation of the push-pull cable and stroke’s programming on
the actuator
System’s components involved: push-pull cables, actuator
In this chapter will be presented the different types of push-pull cables and how to mount them.
10.1 Push-pull cables choice
It can be used 3 different types of push-pull cables. For the connection of the push-pull cable to the actuator, it is nec-
essary to use its proper connection kit. The available kits are for Volvo® cable (E2, E3, C0, C3, C33…), Johnson® cable and
Mercruiser® stern drive cable.
10.1.1 Connection kit
Each kit is enough to connect two push-pull cables.
10.1.2 Standard push-pull cable
Connection kit for Volvo® cable, or
cable type E2, E3, C0, C3, C33…
Connection kit for Johnson® cable Connection kit for Mercruiser® cable
2x
2x
2x
2x
2x
2x 2x
2x
2x
2x
2x
2x
2x
2x
2x
