12.3.2 Parameters to configure the voltage output signals
Parameters FNM Vetus
Nanni
Diesiel
(Toyota)
Hyndai
Steyr Mercury
John Deere Cummins FPT Scania
T4.270 Others IVS 2 Ch Others
QSD 2.8
VM
L1
Motor DX
9 10 13 8 5 7 8 8 6 8 5 5
H1 43 38 40 42 43 37 48 44 45 42 45 28
P1 NA NA NA NA 10 NA NA NA NA NA NA NA
L2 5 0 * 0 * 4 0 43 4 4 NA NA NA NA
H2 21 50 * 50 * 21 50 13 24 22 NA NA NA NA
L3
Motor SX
9 10 13 8 5 7 8 8 6 8 5 5
H3 43 38 40 42 43 37 48 44 45 42 45 28
P3 NA NA NA NA 10 NA NA NA NA NA NA NA
L4 5 0 * 0 * 4 0 43 4 4 NA NA NA NA
H4 21 50 * 50 * 21 50 13 24 22 NA NA NA NA
* For Nanni Diesel / Toyota, L2, H2, L4, H4 must be programmed only if the diesel motor is combined with the electrical
motor. For further information see section 19.4, Programming of actuators with Hybrid engine option.
