Vi.Be.Mac V261 - 2- Output Test; Resetting the Panel Values; Paramater List

44 45
REV. 2.1 22-06-2020REV. 2.1 22-06-2020
Filename:V261 Sheetname:XCG Parameters 1Page 07/04/2020 Sewing machine model(Setting=280M Comparative=280M)
Function
Number
Mode
Digital Function name Unit MIN MAX Value
NORMAL CW . Rotation direction - R
0000 P H. Maximum speed rpm 0 8999 5199
0001 P L. Low speed rpm 0 499 400
0002 P T. Thread trimming speed rpm 0 499 499
0003 P N. Start tacking speed rpm 0 2999 600
0004 P V. End tacking speed rpm 0 2999 400
0005 P M. Medium speed rpm 0 8999 3000
0006 P S. Slow start speed rpm 0 2999 850
0024 P FD. Time to motor drive after presser foot lifter bring down msec 0 998 10
0041 P IL . Cancel of interlock after full pedal heeling - ON
0047 P K8. Reverse run angle from DOWN position to UP position Degree 0 360 224
0050 P SNM. Setting sensor "SEN" input function - OF
0051 P KD . Virtual down Setting - ON
0054 P D8. Needle DOWN position stop angle Degree 10 180 40
0055 P U8. Needle UP position stop angle Degree 10 180 10
0102 A AC . Acceleration time simple setting - L
0103 A ACT. Acceleration time x10msec 6 99 16
0110 A MR. Setting motor pulley diameter mm 20 349 112
0111 A SR. Setting sewing machine pulley diameter mm 20 349 61
0114 A STM. First priority stop => speed control - ON
0300 C IA. Function selection of input signal IA - NO
0303 C IB. Function selection of input signal IB - NO
0306 C IC. Function selection of input signal IC - NO
0309 C ID. Function selection of input signal ID - NO
0312 C IE. Function selection of input signal IE - NO
0315 C IF. Function selection of input signal IF - NO
0324 C IH. Function selection of input signal IH - U
0327 C II. Function selection of input signal II - F
0339 C IM. Function selection of input signal IM - IOB
0342 C IN. Function selection of input signal IN - IOB
0345 C IO. Function selection of input signal IO - IOD
0347 C IOA. Alternating operation of input signal IO - ON
0357 C I1. Function selection of input signal I1 - IOA
0358 C I1L. Logical conversion function of input signal I1 - ON
0370 C I2. Function selection of input signal I2 - IO2
0390 C OA. Function selection of output signal OA - OTC
0395 C OB. Function selection of output signal OB - OTD
0400 C OC. Function selection of output signal OC - KS1
0405 C OD. Function selection of output signal OD - FU
0406 C ODL. Logical conversion function of output signal OD - ON
0410 C OF. Function selection of output signal OF - NO
0416 C O1. Function selection of output signal O1 - OTE
0426 C O3. Function selection of output signal O3 - NO
0427 C O3L. Logical conversion function of output signal O3 - ON
0431 C O4. Function selection of output signal O4 - NO
0435 C O5. Function selection of output signal O5 - NO
0449 C OM. Function selection of output signal OM - KS4
0453 C ON. Function selection of output signal ON - KS3
0457 C OO. Function selection of output signal OO - OT3
0477 C A1. Logic [AND] module A1 input function selection - IO6
0480 C N1. Logic [AND] module N1 output function selection - OTA
0482 C N2. Logic [AND] module N1 output function selection - KS3
0483 C N2L. Logic [AND] module N2 setting of Hi /Low logic - ON
0484 C A2. Logic [AND] module A2 input function selection - IOC
0487 C N3. Logic [AND] module N3 output function selection - OT2
0488 C N3L. Logic [AND] module N3 setting of Hi /Low logic - ON
0489 C N4. Logic [AND] module N4 output function selection - OP
0491 C A3. Logic [AND] module A3 input function selection - IOE
0494 C N5. Logic [AND] module N5 output function selection - OTB
0496 C N6. Logic [AND] module N6 output function selection - FU
0497 C N6L. Logic [AND] module N6 setting of Hi /Low logic - ON
0498 C OR. Logic [OR] module input function selection - SVM
0501 C R1. Logic [OR] module R1 output function selection - OT2
0502 C R1L. Logic [OR] module R1 setting of Hi /Low logic - ON
0503 C R2. Logic [OR] module R2 output function selection - KS4
0800 F COA. Set No. of stitches A for cutter output (Setting the delay time during chain-off output ON) Stitches 0 99 10
0801 F COB. Set No. of stitches B for cutter output (Setting the delay time during chain-off output OFF) Stitches 0 99 17
0802 F COC. Set No. of stitches C for cutter output Stitches 0 99 24
0806 F SD. Delay time to when SL output turns from OFF to ON msec 0 508 40
0813 F O1B. OT1 output blower output setting - ON
0814 F O2M. OT2 output chain-off output setting - ON
0815 F O3M. OT3 output cutter output setting - ON
0818 F CTM. Status of cutter output photo switch (I*2) signal according to OT3 output - ON
0823 F CAT. Automatic thread trim setting after cutter sensor is turned off - ON
0919 G FD. Time to motor drive after presser foot lifter bring down msec 0 998 10
1000 H LHH. Upper limit of maximum speed [H] x100rpm 0 99 52
1001 H LHL. Lower limit of maximum speed [H] x100rpm 0 99 10
1006 H LNH. Upper limit of start/end tacking (condensed stitching) speed x100rpm 0 99 40
20.4.2- Output test
While the machine is operating, it is possible to see the function and the signal changing from
OF to ON and viceversa.
The following will then appear on the display:
O A D. O F output signal 0 A = THREAD PULLER OFF
The OUTPUT signal value of the 0 A d parameter is displayed.
The normal factory-set parameters are as follows:
Press the DOWN arrow
Display of all the OUTPUTS (TEST OUTS) with the possibility to test them manually by pressing
button D on the console.
Press the UP and DOWN arrows at the same time in order to exit from this mode
FUNCTION DISPLAY
Air vacuum oAd
Trimmer oBd
Press foot point cylinder oCd
Presser foot up oFd
Presser foot high pressure o1d
Needle cooling o2d
Puller down o3d
FUNCTION DISPLAY
Air vacuum oAo
Trimmer oBo
Press foot point cylinder oCo
Presser foot up oFo
Presser foot high pressure o1o
Needle cooling o2o
Puller down o3o
20.5- Resetting the panel values
On the display appears:
☐ 2 - 9 9
Press the DOWN arrow key and B and C button in the same time.
The following will then appear on the display:
P - r (r mode)
R E S E T
Keep pressed D key in order to start the resetting cycle and keep it pressed DOWN until the

The following appears on the control panel display:
☐ 2 - 9 9
20.6- Paramater list
