46 47
REV. 2.1 22-06-2020REV. 2.1 22-06-2020
Filename:V261 Sheetname:XCG Parameters 2Page 07/04/2020 Sewing machine model(Setting=280M Comparative=280M)
1008 H LMH. Upper limit of medium speed [M] x100rpm 0 99 50
1009 H LML. Lower limit of medium speed [M] x100rpm 0 99 15
1102 J CWC. Rotation direction changeover prohibit - ON
1103 J 12C. 1-2 position changeover prohibit - ON
1104 J SLC. Slow start changeover prohibit - ON
1106 J JKC. Not used - ON
1107 J SBC. Start tacking validity changeover prohibit - ON
1108 J SNC. No. of start tacking stitches changeover prohibit - ON
1109 J EBC. End tacking validity changeover prohibit - ON
1110 J ENC. No. of end tacking stitches changeover prohibit - ON
1111 J SKC. Start tacking type changeover prohibit - ON
1112 J EKC. End tacking type changeover prohibit - ON
1113 J TSC. Pattern stitching validity changeover prohibit - ON
1114 J TNC. Pattern stitching No. of stitches and times changeover prohibit - ON
1115 J MDC. Pattern mode pattern changeover prohibit - ON
1117 J BPC. Prohibit the teaching mode key switches on control switch panel - ON
1118 J BSC. Prohibit the following key switches on control switch panel - ON
1120 J BKC. Prohibit the key switches on the control switch panel before thread trimming - ON
1121 J NSV. The use number is preserved by the number call. - ON
1339 O I1. Function selection of making I1 two input signal functions - IO9
1340 O I1L. Logical conversion function to make I1 two input signal functions - ON
1352 O I2. Function selection of making I2 two input signal functions - IO8
1430 Q MOB. Not used. Stitches 0 99 3
1500 S KSM. KS1, KS2 output run mode - ON
1501 S SQS. Simple sequence start conditions - GO
1503 S NS1. Simple sequence output KS1 output beginning is time or the number of stitch is selected - ON
1504 S NE1. Simple sequence output KS1 output is time or the number of stitch is selected - ON
1505 S S1S. Output beginning standard of simple sequence output KS1 - IN
1508 S NE2. Simple sequence output KS2 output is time or the number of stitch is selected - ON
1509 S S2S. Output beginning standard of simple sequence output KS2 - IN
1512 S NE3. Simple sequence output KS3 output is time or the number of stitch is selected - ON
1513 S S3S. Output beginning standard of simple sequence output KS3 - IN
1515 S NS4. Simple sequence output KS4 output beginning is time or the number of stitch is selected - ON
1516 S NE4. Simple sequence output KS4 output is time or the number of stitch is selected - ON
1517 S S4S. Output beginning standard of simple sequence output KS4 - IN
1519 S K11. KS1 output start [Time]/[No. of Stitches] setting
0 99 3
1521 S K21. KS2 output start [Time]/[No. of Stitches] setting
0 99 0
1522 S K22. KS2 output [Time]/[No. of Stitches] setting
0 99 25
1523 S K31. KS3 output start [Time]/[No. of Stitches] setting
0 99 0
1524 S K32. KS3 output [Time]/[No. of Stitches] setting
0 99 12
1525 S K41. KS4 output start [Time]/[No. of Stitches] setting
Error code Probable cause Inspection
Is the power voltage too low?
Is the power supply capacity too small?
NOTE: It does this display when power supply
is turned OFF, but this is not an error
Check the power voltage.
Check the power supply capacity.
E1
Is the wire to the motor short-circuited?
Is the sewing machine load torq ue too high?
Check the motor wiring.
Check the sewing machine
E2
Is the power voltage too high?
Is the sewing machine inertia too high?
Check the power voltage.
Lengthen the deceleration time.
(Refer to DC in [A] mode)
E3
Is the connector to the motor encoder securely
inserted?
Are the signal from the motor encoder correct?
Is the sewing machine locked?
Is the motor locked?
Check the connector insertion.
Check the encoder signal.
(Refer to [E] mode)
Check the sewig machine.
Check the motor.
E4
Is the motor connector securely inserted?
Are the signal from the motor connector correct?
Check the motor connector
insertion.
Check the motor connector.
E6
Is an extraordinary signal inputted? (the signal as
it repeats ON/OFF at the high frequency)
Does the noise from outside enter an input signal
Check the input signal.
Remove a noise source.
E8
Is the position detector connector securely
inserted?
Are the signal from the detector correct?
(UP/DOWN signal interruption)
Check the detector insertion.
Check the decettor UP/DOWN
signal. (refer to [E] mode)
E9
Is the solenoid wiring short-circuited?
Solenoid defect (coil defect)
Checkn the solenoid wiring.
Replace the solenoid.
M5
A error of the copy mode using the control panel.
Is the control panel connector securely inserted?
The voltage or the type of control panel is
Check the connector insertion.
Check the voltage and the type
are right.
MA
The position data of the internal lever unit is
defective.
When power supply is turned ON.
The pedal is not neutral position.
The pedal is neutralized.
(it returns automatically 1 second
later)
20.7- Error list
