Vi.Be.Mac V261 - Pneumatic Diagram; Topographic Pneumatic Diagram

54 55
REV. 2.1 22-06-2020REV. 2.1 22-06-2020
1
23
456
7
8
9
10
11
12
Sewing Machine Box MITSU
EV6 High Pressure presser foot (O1) EV2 Air vacum (OA) EV1 Thread Trimmer (OB) EV7 Puller down (O3) EV4 Pressure foot small cylinder (OC)
OUTPUT CONNECTIONS:
EV3 Low Pressure presser foot (OD) EV5 Needle blowing (O2)
1
23
456
7
8
9
10
11
12
13
14
15
Option B Box MITSU
Pin 2 EV1 (OB) Green Pin 4 EV2 (OA) Yellow Pin 7 EV3 (OD) Gray Pin 12 EV4 (OC) Pink Pin 11 +24Vcc Brown N.C. White Pin 12 EV5 (O2) Green Pin 3 EV6 (O1) Yellow Pin 15 EV7 (O3) Gray N.C. Pink N.C. Brown N.C. White
1 2 3 4 5 6 7 8 9
10 11 12 13
25 24 23 22 21 20 19 18 17 16 15 14
DB25
Female
Pin 11 +24Vcc Brown
Pin 1 EV1 Green
Pin 14 EV2 Yellow
Pin 2 EV3 Gray
Pin 15 EV4 Pink
Pin 3 EV5 Green
Pin 16 EV6 Yellow
Pin 4 EV7 Gray
N.C. White
N.C. Brown
N.C. Pink
N.C. White
CB54 S.M. 6X0.5MM² L.80Cm
CB54 O.B. 6X0.5MM² L.80Cm
Title Author File Revision
Document
Date Sheets
V261 Output connections Falzi Giordano Vi.Be.Mac.
Y:\Mac ... V261_Electrical_Equipment_V2.0.DSN
1.0 29/05/2019 4
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
A
A
B
B
C
C
D
D
E
E
F
F
G
G
H
H
I
I
J
J
K
K
L
L
T e c h n o l o g y
VI.BE.MAC.
m e n
and
V261
COD. COMPONENTE:
P01
13-11-2019
REVISIONE :
DATA:
Ø8 ROSSO TRASPARENTE
Ø4 L78cm VERDE TRASPARENTE
Ø4 L108cm GIALLO
Ø4 L85cm BLU TRASPARENTE
Ø4 L107cm NERO
Ø4 L110cm ROSSO TRASPARENTE
Ø4 L120cm BIANCO
Ø4 L120cm TRASPARENTE
24. PNEUMATIC DIAGRAM
24.1- Topographic Pneumatic Diagram
