6.1.3. GC Plus Zero Air
Air Information Display
Air Outlet Pressure Gauge
Air Outlet Pressure Regulator
Air On/Off Switch
Service Indicator
6.2. BACK VIEW
6.2.1. PG Plus Rack - H
2
Only Model
H
2
Outlet
H
2
Outlet Relief Valve
IO Board Option
External Water Tank Inlet
110/230 V Inlet
USE CORRECT FUSE
REMOVE PLUG BEFORE USE
