VICI DBS PG Plus Rack 100 - GC Plus Zero Air Rack

15
PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL
www.vicidbs.com
Version 2.00.0000
6.2.2. PG Plus Rack - H
2
+ Zero Air Model
H
2
Outlet
H
2
Outlet Relief Valve
IO Board Option
External Water
Tank Inlet
110/230 V Inlet
REMOVE PLUG BEFORE USE
USE CORRECT FUSE
Compressed Air Inlet
Zero Air Outlet
6.2.3. GC Plus Zero Air Rack
110/230 V Inlet
USE CORRECT FUSE
Compressed Air Inlet
Zero Air Outlet
