PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL
www.vicidbs.com
Version 2.00.0000
Hydrogen ow rate at Standard
Temperature and Pressure
(20°C, 1 barg)
Cell-Type:
Proton Exchange Membrane (PEM)
100% Ti Cell
Part-Number (PN)
PG Plus Rack 100 0-100 cc/min Cell-PN: DB-CELL-MI
PG Plus Rack 160 0-160 cc/min Cell-PN: DB-CELL-MI
PG Plus Rack 250 0-250 cc/min Cell-PN: DB-CELL-MU1
PG Plus Rack 300 0-300 cc/min Cell-PN: DB-CELL-MU1
PG Plus Rack 500 0-500 cc/min Cell-PN: DB-CELL-MU2
PG Plus Rack 600 0-600 cc/min Cell-PN: DB-CELL-MU2
4.2. ZERO AIR OPTION
DB-FH-1800 or DB-FT-1800 DB-FH-5000 or DB-FT-5000
Flow mL/min 1800 5000
Purity - hydrocarbons + CO <0.1 ppm
Inlet pressure barg (psig) 4.5 to 10 (65 to 145)
Inlet air quality Clean dry compressed air ISO8573-1:2010 Class 1.2.1
Max outlet pressure barg (psig) 5 (73)
Max HC in 100 ppm
Max CO in 50 ppm
Technology Platinum catalyst
LED indicators Power on/off, system ready, errors
Warm up time (minutes) 45
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Power consumption (watts) 200 550
Operating temperature ºC (ºF) 15 to 35 (59 to 95)
Inlet connection 1/4” Compression
Outlet connection 1/8” Compression
Certication CE, FCC, MET (UL and CSA compliant)
MODELS & SPECS
