PG PLUS RACK + ZERO AIR
& GC PLUS RACK USER MANUAL
www.vicidbs.com
Version 2.00.0000
WARNING: Any changes or modications to this equipment not expressly approved
by the manufacturer may void the user’s authority to operate the equipment.
PG PLUS
100 RACK
PG PLUS
160 RACK
PG PLUS
250 RACK
PG PLUS
300 RACK
PG PLUS
500 RACK
PG PLUS
600 RACK
Flow mL/min 100 160 250 300 500 600
Purity >99.9996%
Dewpoint at 7 barg (100 psig) -25ºC (-13ºF)
Outlet pressure barg (psig) 0.5 to 11 (7 to 160)
Technology PEM (Proton Exchange Membrane) - 100% Titanium cell
Drying system Regenerative permeation membrane
Deionized water quality Minimum < 1 µS/cm @25ºC - 1 MΩ cm @25ºC - ASTM II
Recommended < 0.2 µS/cm @25ºC - 5 MΩ cm @25ºC - ASTM II
External water tank (liters) External 10 liter bottle and internal pump
Safety Automatic shut down - internal/external hydrogen leak,
overpressure and low water
Display Touch screen with operating parameters, system status and safety alarms
LED indicators Power on/off, system ready, errors
Interface USB mod A
Electrical supply 110-120V 60Hz / 220-240V 50Hz
Power consumption (watts) 65 95 115 130 180 280
Dimensions mm (inches) 19” Rack W x 3U H x 500D (19.6)
Weight kg (lbs) 17 (37.4) 19 (41.9)
Shipping dimensions mm (in) 720W x 375H x 565D (28.3W x 14.7H x 22.2D)
Shipping weight kg (lb) 21 (46) 23 (50)
Operating temp
o
C (
o
F) 15 to 35 (59 to 95)
Outlet connection 1/8" Compression
Certication CE, FCC, MET (UL and CSA compliant)
MODELS & SPECS
4. SPECIFICATIONS
4.1. PG PLUS RACK
