Vicon CMP 3001F - Conditioner; Mower; Technical Specification

G0202MKD3 EN21
5.8 Technical specification
5.8.1 Mower
- * ex-factory one 4-mm-ring per drum fitted, set of 8-mm-rings available as option (see sect. 6.2).
5.8.2 Conditioner
MACHINE TYPE CMP 3001F
Type code
MD
Working width 300 cm (8’6”)
Weight (mass) 9316 N (950 kg; 2094 lb)
Mowing drums 4
Blades 5x ccw, 5x cw
Grease nipples 10 (excl. drive shafts)
Skid discs 4
Cutting height adjustment range* 3x 8 mm with rings
Drive:
- power requirement
- pto speed
- direction of pto rotation
59 kW (80 hp)
1000 rpm
clockwise
with freewheel clutch
Hitch category cat. II
Ground adaptation 2 compression spring units
Hydr. power requirement:
- connections
- max. pressure
1 (1 single acting valve with floating
position)
200 bar (2900 psi)
MACHINE TYPE TK 3001
Type code
MD
Matching mower type CMP 3001F
Swath spreading width 110 - 300 cm (43” - 118”)
Weight (mass), incl drive 2451 N (250 kg; 551 lb)
Chain drive with shearbolt safety
