Vicon CMP 3001F - Torque Values for International Metric Thread Joints

G0202MKD3 NL22
5.9 Torque values for international metric thread joints
All bolted joints on this machine must be torqued in accordance with the values given in this table below unless indicated
otherwise (e.g. in Parts List or Installation Instruction, etc.)
On all Kverneland Geldrop machines 8.8 is both standard and minimum quality used. If not indicated anyhow use this quality
for determination of torque (in most cases the quality can be found on the head of the respective bolt).
* Material quality in acc. with DIN ISO 898.
** Value in brackets means inch-pounds (in-lb).
*** Size of jaw of lock bolts and nuts with toothed flange are given (metric values only) in brackets if different
from standard.
-
The listet values are applicable for dry or slightly oiled joints.
- When a stiff grease is applied decrease the given value by 10%. Do not use plated bolts/screws/nuts without
grease.
- In case lock nuts, lock screws or lock bolts are used the given value must be increased by 10%.
-
Torque value of wheel nuts M18x1,5 shall be 270 Nm (200 ft-lb)!
Thread
Torque value Size of jaw***
8.8* 10.9* 12.9*
Nm ft-lb** Nm ft-lb** Nm ft-lb** mm inch
M3 1.3 (11.5) 1.8 (16) 2.1 (18.6) 6 7/32
M4 2.9 (25.5) 4.1 (36.5) 4.9 (43.5) 7 9/32
M5 5.7 (50.5) 8.1 (71.5) 9.7 (86) 8 5/16
M6 9.9 7.3 14 10.3 17 12.5 10 13/32
M8 24 17.7 34 25 41 30.3 13 33/64
M10 48 35.4 68 50.2 81 59.8 17 (15) 11/16
M12 85 62.7 120 88.6 145 107 19 (17) 3/4
M14 135 99.6 190 140 225 166 22 (19) 7/8
M16 210 155 290 214 350 258 24 (22) 1
21/128
M18 290 214 400 295 480 354 27 1
9/128
M20 400 295 570 421 680 502 30 1
3/16
M22 550 406 770 568 920 679 32 1
17/6 4
M24 700 517 980 723 1180 871 36 1
27/64
M27 1040 767 1460 1077 1750 1291 41 1
79/128
M30 1410 1041 1980 1461 2350 1734 46 1
13/16
M33 1910 1410 2700 1996 3200 2362 50 1
31/32
M36 2450 1808 3450 2546 4150 3063 55 2
11 / 6 4
M39 3200 2362 4500 3321 5400 3985 60 2
3/8
Tensile strength Material quality acc. to DIN ISO 898
8.8 10.9 12.9
up to and incl. M16 over M16
N/mm
2
808 830 1040 1220
lbf/sq.in. 117,222 120,414 150,880 176,994
