Assembly - attachment
29
Adjusting the
working height
Check that the machine's cutting unit is in the working position.
The tractor's hydraulic outlet must be locked in the open position
(floating position).
Raise/lower the machine until the measurement shown is
obtained.
Lock the machine's suspension securely with the chain as shown.
If the machine is fitted with high skids* the working height of the hitch
must be 440 - 470 mm (17
5
/
32
” - 18
1
/
2
”).
* Extra equipment.
»Optional equipment« page 84
Check that the hitch is fitted horizontally on the tractor.
