Troubleshooting
103
Troubleshooti ng
Hydraulic system
Cutterbar
Fault Possible cause Remedy Page
The machine hangs
directly to the rear
during mowing
There is too much downward pressure
from the cutterbar
Adjust the ground pressure
42
Hydraulic
The machine's hydraulic functions do
not work
Check that the hydraulic hoses are
correctly connected to the tractor's
outlet
34
Make sure that the tractor hydraulics
are engaged
34
Insufficient amount of oil or oil
pressure from the tractor
The machine
cannot be raised to
the transport
position
The machine's transport lock is not
activated
Pull in the cord and activate the
transport lock
35
Fault Possible cause Remedy Page
The machine hangs
directly to the rear
during mowing
There is too much downward pressure
from the cutterbar
Adjust the ground pressure
42
The spring catch has not been set
correctly
Check the spring catch
78
The hitch is not at the correct height Set the height of the hitch 29
Uneven stubble
Driving too slowly Increase speed 22
The tractor RPM on the PTO is too low Check RPM 22
The knives are blunt or individual
knives are missing
Turn or replace the knives
65
The machine is not correctly balanced Adjust the ground pressure 42
The hitch is not at the correct height Set the height of the hitch 29
The ground pressure is too low Adjust the ground pressure 42
Stripes in the
stubble
[1]
The cutterbar is not correctly angled for
the crop in question
Adjust the angle of the cutterbar 42
Increase speed
The cutterbar is fitted with high skids
[2]
Remove the high skids
[2]
Note! The field must be free of stones
100
Build up of crop on the cutting discs Increase speed
Stubble too high Cutterbar angle is too small Adjust stubble height 42
The cutterbar gets
abnormally warm
Too much oil in the cutterbar Inspect the oil level in the cutterbar 62
Wrong oil type Change to the correct oil type 109
