Conversion table
Lubricants
Torque moment
The above tables are valid unless otherwise indicated in the
instruction manual for this machine.
Basic unit: SI - unit Conversion figures:
Length 1 m 39.4 in = 3.3 ft = 1.1 yd = 0.00062 miles (US)
Area
1 m
2
1.2 yd
2
= 10.8 ft
2
= 0.00025 acre = 0.0001 ha
Volume
1 dm
3
(1 l) 61 in
3
= 0.035 ft
3
= 0.22 gallons (lmp) = 0.26 gallons (US)
Speed 1 m/sec 3.6 km/h = 2.24 mph = 3.28 ft/sec
Power 1 N 0.10 kp = 0.22 lbf
Effect 1 kW 1.36 hp = 102 kpm/sec
Mass 1 kg 2.2 lb = 0.0197 cwt = 35 oz
Torque moment 1 Nm 0.102 kpm = 8.8 lb-in = 0.74 ft/lb.
Pressure 1 bar
0.01 atm. (kp/cm
2
) = 0.14 psi
R.P.M
min
-1
= revolutions/min = rpm
Supplier Oil for the cutterbar Oil for the transmission Grease nipples
BP Energear SHX-M 75W-90 Energear Hypo 80W-90 Energrease L 21 M
CASTROL EP 80W EPX 80W/90 Castrol Entrepreneur
Grease
STATOIL Gearway G4 80W-90 Gearway G5 80W-90 CreaseWay CaH 81
Q8 T35 80W T 55 80 W/90 Rembrandt EP1
MOBIL OIL Mobilube HD GX-A 80W W Mobilube 80W-90 Mobilgrease EAL 1
SHELL Spirax GX 80 W Spirax MB 90 Retinax HD 2
Retinax HD X2
TEXACO Geartex EP-A 80W Geartex EP-A 80W-90 Multifak t EP 2
OK Gearoil GL 5 80 W OK Gearoil GL 5 80 W-90 Compound 2
Tightening torque for grade 8.8 black and/or galvanised and ungreased bolts when tightened on a smooth surface or a plain washer
Thread dia.
mm
5 6 8 101214162022
Nm 5.5 10 24 47 81 128 197 385 518
ft/lb 4 7.5 18 35 60 94.5 145.5 284 382.5
