Assembly - attachment
27
The machine is fitted with attachment points for both category 2
and 3.
Mount the machine onto the tractor's lift arms.
Raise the machine's suspension clear of the ground.
Check that the tractor's lift arms are at the same height.
• If not, lower the machine's suspension down to the ground and
adjust the tractor's lift arms.
Fold the support leg up as shown.
