Assembly - attachment
30
Bevel gear - tractor
Checking the rpm
Maintain the rotational speed on the tractor PTO outlet
It is dangerous to connect a tractor with a PTO of 540 rpm to a
machine set for a PTO of 1000 rpm, and vice versa.
The machine is not designed for this speed.
It can result in damage on the machine and be a danger for persons
nearby.
The transmission can be switched to 2 modes, so that both rotational
speeds, 540 rpm or 1000 rpm, can be used.
From the factory the machine is adapted to tractors that run at 1000
rpm on the PTO.
Whenever possible, one should always aim to run the PTO outlet at
1000 rpm.
It is especially recommended that tractors with power above 70 kW
(90 hp) on the PTO outlet run at a rotational speed of 1000 rpm, as
high rpm exerts less load on the PTO shaft.
RPM on the PTO outlet
1000 rpm
From the factory the machine is adapted to tractors that run at 1000
rpm on the PTO.
