Vicon Extra 332 - Page 93

Maintenance
93
 Remove the bolt and knife from the cutting disc.
 Fit the knife and bolt on the new cutting disc.
 Tighten up the bolt with a torque wrench to the torque shown.
 Apply Loctite 242 or a similar product to all bolts.
 Fit the cutting disc on the cutterbar.
 Tighten up the bolts with a torque wrench to the torque shown.
 Pull and release the lock.
 Close the front guard.
Bolt
Bolt
95 Nm +/- 5
70 ft/lb. +/- 3
Loctite
242
Loctite 242
Bolt
80 Nm +/- 5
59 ft/lb. +/- 3
