Vicon Extra 332 - Page 95

Maintenance
95
 Remove the guard around the PTO shaft between the transmission
and the cutterbar.
 Remove the top cover from the cone.
 Remove the bolts and replace the PTO shaft.
 Clean the bolts.
 Apply Loctite 242 or a similar product to all bolts.
 Fit the bolts and tighten to the torque shown.
 Fit the cone's top cover.
Bolts
79 Nm
58 ft/lb
Loctite
242
Loctite 242
