5.18.4 Configuration
The DVR is configured by On Screen Menu. Refer to the corresponding manual for an explanation of the
various configuration items.
The DVR should be configured for RS485 type communication, with an appropriate identification address and
baud rate.
5.18.4.1 OSM Configuration
Connect the DVR directly to the keyboard and a monitor to the MONITOR 1 output.
starts DVR configuration.
The DVR shows the on screen menu; the keyboard display indicates the mode change:
enters the selected submenu
end of configuration
Joystick
: for movement within the menus and changing the values.
5.18.5 Special SEARCH menu
enters the special SEARCH menu
exits the menu
Joystick
: for movement within the menus and changing the values.
Wa
rning: if the DVR stays in SEARCH mode after exiting the menu, press STOP (
) to return to
normal mode.
5.18.6 Special COPY menu
enters the special COPY menu
cancels the copy operation and deletes any on screen messages
exits the menu
Warning: the copy operation or, when appropriate, its cancellation by pressing
, should be completed
before
exiting the menu
Joystick
: for movement within the menus and changing the values.
5.18.7 Dedicated Functions
As well as the normal procedure for selecting input videos, the SONY DVR is provided with numerous other
functions that are activated by pressing key combinations corresponding to the keys on the DVR’s local keypad.
The
key is used to change the number of the unit responding to the command.
