6.6.6 Dome movement
The keyboard can control the dome either with fixed speed (Elbex EKB100J emulation mode) or with variable
speed.
6.6.6.1 Fixed speed
The dome moves in pan/tilt with fixed speed. A little movement of the joystick moves slightly the dome on the
desired direction and then stops it. A wider joystick movement moves the dome with the last used speed.
Request fixed speed by pressing
.
Speed is
set with
(1 low speed ÷ 8 highest speed).
6.6.6.2 Variable speed
The speed changes according the joystick position. Any previously set speed value is neglected.
Request variable speed by pressing
.
6.6.7 Autopan
: start
: stop
: start left autopan
: start right autopan
6.6.8 Movement limits
Left limit
Right limit
:
:
set
remove
:
:
set
remove
6.6.9 Preset, scan, home
(1÷99): store current position as preset no.X
: store current position as local alarm position
(1÷99): store current position as alarm position no.X
(1÷99): move to preset position no.X
: move to local alarm position
(1÷99): move to alarm position no.X
: move to Home position (equivalent to Scan 1).
: move to the last requested position.
: move to the alarm return position.
