Page 71
MNVADCJ01_1729_EN
6.6.10 Auto scan control
6.6.10.1 Control
Norm
al
Alarm
:
:
start
stop
:
:
start
stop
6.6.10.2 Preset positions
: add all preset positions
(1÷99): add a single preset position
: remove all preset positions
(1÷99): remove a single preset position
(1÷99): dwell time in seconds after reaching a position
: request a maximum speed movement
(1÷8): set a reduced speed factor
6.6.10.3 Alarm positions
: add all alarm positions
(1÷99): add a single alarm position
: remove all alarm positions
(1÷99): remove a single alarm position
(1÷99): dwell time in seconds after reaching a position
: request a maximum speed movement
(1÷8): set a reduced speed factor
6.6.11 Timers
(00÷56): autopan stop
00: continuous; 01÷23: from 5 to 115 minuts (step 5 minutes); 24÷44: from 2 to 12 ore (step 30 minuts); 45÷56:
from 13 to 24 hours (step 1 hour)
(1÷8, 00÷28): aux contacts reset.
The first X cypher is the number of Aux contact (1÷8); the following ones the time:
00: continuous; 01÷05: from 1 to 5 minuts (step 1 minute); 06÷15: from 10 to 55 minuts (step 5 minuts); 16÷27:
from 1 to 12 hours (step 1 hour); 28: 24 hours
(00÷28): wiper stop*
(00÷28): washer stop*
(00÷28): light stop*
(00÷28): heater stop*
(00÷28): fan stop*
