Page 77
MNVADCJ01_1729_EN
6.7.3.1 OSM Setup
Connect the dome directly to the keyboard and connect a monitor to the dome video outlet.
The DCJ keyboard enters special mode while the dome is being set up. When
is pressed for the first time,
the keybo
ard is reset to normal operation.
starts dome setup.
The dom
e shows the menu on video; the keyboard shows the mode change on the display:
end setup
enter submenu
Joystick
: shifts the cursor within the menus
Joy
stick
: changes the value shown by the cursor.
Whe
n dome movement is required in OSM mode, the
key should be held down while the joystick is being
moved
.
Activation of Zoom Tele a
nd Zoom Wide, when required, is obtained by rotating the joystick
.
6.7.3.2 Direct setup
Some parameters can be set up by pressing the keys or inserting a special code:
Line lock phase:
increase, decrease.
Automatic autoflip:
enable, disable
Zoom speed:
(1÷4); slow zoom (X = 1), fast zoom (X = 4)
Pan spe
ed proportional to thezoom:
enabled, disabled
Digital zoom:
disabledd, (2÷8) enabled 2x÷8x
Focu
s speed:
(1÷4); focus slow (X = 1), focus fast (X = 4)
Autofoc
us:
on/off (toggle), off
Autoiris
: on
